Specialized In Die Casting Service And Parts with Professional Design and Development

102,No.41,Changde Road,Xiaojiejiao,Humen Town,Dongguan,China | +86 769 8151 9985 | sales@hmminghe.com

Oxygen-Nitrogen-Carbon Infiltration Of Aluminum Die

Publish Time: Author: Site Editor Visit: 13477

Oxygen-Nitrogen-Carbon Infiltration Of Aluminum Die

Oxygen and nitrocarburizing treatment can be carried out in a pit carburizing furnace, using liquid ammonia, oxygen and nitrogen as infiltrating agents. The inner wall of the furnace pot, the inner surface of the furnace cover and the loading frame are all coated with water glass graphite paint and dried at 200°C to extend the service life.

The temperature of the empty furnace is raised to 620°C, the mold 3Cr2W8V steel mold is loaded into the furnace, nitrogen is introduced into the furnace to remove air, the nitrogen flow is 0.4-0.5M/h, and the pressure is 20×10∧4Pa (2kgf/cm2) Exclude air for 1h. Then raise the furnace temperature to 570℃, stop the nitrogen flow, and change the flow of ammonia gas with a flow rate of 0.5-0.6m3 and a pressure of 7×10∧4Pa (7kgf/cm2). At the same time, oxygen gas with a flow rate of 50-80mL/min and pressure It is 3×10∧4Pa (0.3kgf/cm2).

After being kept at 570°C for 2h, the furnace temperature is raised to 620°C and kept for 2h, and the treatment process is over. Cut off the ammonia and oxygen, change to nitrogen to exhaust the ammonia and oxygen in the furnace, and cut off the power supply to reduce the furnace temperature. When the furnace temperature drops below 450℃, take the mold out of the furnace and put it into the tank wall Slowly cool to room temperature in the cooling tank with water.

After co-infiltration, the surface hardness is 891HV0.05, the surface layer is white and bright epsilon layer, the thickness is 0.02-0.023mm, the main nitride phases are Fe3N and Fe4N, and there is a small amount of Fe3O4, and there is no obvious Fe2N brittle phase. Connected to ε is a N-containing α-Fe diffusion layer, and the total nitriding depth of the white bright layer plus the diffusion layer is 0.2-0.28mm. The heart is primitive tissue + tempered cable body.

More than a thousand pieces of 3Cr2W8V steel aluminum alloy die-casting die treated by the above process are die-casted, and the surface is still smooth and intact, and the demolding is smooth, without adhesion, peeling, scratches, and corrosion.


Please keep the source and address of this article for reprinting:Oxygen-Nitrogen-Carbon Infiltration Of Aluminum Die


Minghe Die Casting Company are dedicated to manufacture and provide quality and high performance Casting Parts(metal die casting parts range mainly include Thin-Wall Die Casting,Hot Chamber Die Casting,Cold Chamber Die Casting),Round Service(Die Casting Service,Cnc Machining,Mold Making,Surface Treatment).Any custom Aluminum die casting, magnesium or Zamak/zinc die casting and other castings requirements are welcome to contact us.

ISO90012015 AND ITAF 16949 CASTING COMPANY SHOP

Under the control of ISO9001 and TS 16949,All processes are carried out through hundreds of advanced die casting machines, 5-axis machines, and other facilities, ranging from blasters to Ultra Sonic washing machines.Minghe not only has advanced equipment but also have professional team of experienced engineers,operators and inspectors to make the customer’s design come true.

POWERFUL ALUMINUM DIE CASTING WITH ISO90012015

Contract manufacturer of die castings. Capabilities include cold chamber aluminum die casting parts from 0.15 lbs. to 6 lbs., quick change set up, and machining. Value-added services include polishing, vibrating, deburring, shot blasting, painting, plating, coating, assembly, and tooling. Materials worked with include alloys such as 360, 380, 383, and 413.

PERFECT ZINC DIE CASTING PARTS IN CHINA

Zinc die casting design assistance/concurrent engineering services. Custom manufacturer of precision zinc die castings. Miniature castings, high pressure die castings, multi-slide mold castings, conventional mold castings, unit die and independent die castings and cavity sealed castings can be manufactured. Castings can be manufactured in lengths and widths up to 24 in. in +/-0.0005 in. tolerance.

ISO 9001 2015 certified manufacturer of die cast magnesium and mold manufacturing

ISO 9001: 2015 certified manufacturer of die cast magnesium, Capabilities include high-pressure magnesium die casting up to 200 ton hot chamber & 3000 ton cold chamber, tooling design, polishing, molding, machining, powder & liquid painting, full QA with CMM capabilities, assembly, packaging & delivery.

Minghe Casting Additional Casting Service-investment casting etc

ITAF16949 certified. Additional Casting Service Include investment casting,sand casting,Gravity Casting, Lost Foam Casting,Centrifugal Casting,Vacuum Casting,Permanent Mold Casting,.Capabilities include EDI, engineering assistance, solid modeling and secondary processing.

Casting Parts Application Case Studies

Casting Industries Parts Case Studies for: Cars, Bikes, Aircraft, Musical instruments, Watercraft, Optical devices, Sensors, Models, Electronic devices, Enclosures, Clocks, Machinery, Engines, Furniture, Jewelry, Jigs, Telecom, Lighting, Medical devices, Photographic devices, Robots, Sculptures, Sound equipment, Sporting equipment, Tooling, Toys and more.


What Can we help you do next?

∇ Go To Homepage For Die Casting China

Casting Parts-Find out what we have done.

→Ralated Tips About Die Casting Services


By Minghe Die Casting Manufacturer |Categories: Helpful Articles |Material Tags: , , , , , ,Bronze Casting,Casting Video,Company History,Aluminum Die Casting |Comments Off

MingHe Casting Advantage

  • Comprehensive Casting design software and skilled engineer enables sample to be done within 15-25 days
  • Complete set of inspection equipment & quality control makes excellent Die Casting products
  • A fine shipping process and good supplier guarantee we can always deliver Die Casting goods on time
  • From prototypes to end parts, upload your CAD files, fast and professional quote in 1-24 hours
  • Wide-ranging capabilities for designing prototypes or massive manufacturing end use Die Casting parts
  • Advanced Die Casting techniques (180-3000T Machine,Cnc Machining, CMM) process a variety of metal & plastic materials

HelpFul Articles

Oxygen-Nitrogen-Carbon Infiltration Of Aluminum Die

Oxygen and nitrocarburizing treatment can be carried out in a pit carburizing furnace, using liquid

The Measures To Improve The Quality Of Carbon-Manganese Steel Rudder Stock

The rudder stock is the shaft on which the rudder blades rotate. The rudder blades are rotated by th

The Reasons For Excessive Carbon Content In the Lost Foam Castings Production

After analyzing and summarizing various possible causes of excessive carbon content in the productio

The Performance Of 785MPa Low-Carbon Copper-Bearing Ship Plate Steel

On-line direct quenching-tempering process (DQ-T) is gradually used to produce high-strength steel,

Improvement and optimization of ultra-low carbon martensitic stainless steel smelting process

Ultra-low carbon martensitic stainless steel (06Cr13Ni46Mo and 06Cr16Ni46Mo) is an important materia
